Wireless Camera System
Introduction:
Watch over your properties with this new 2.4 GHz digital wireless security camera system. The 7" LCD monitor can
support up to 4 cameras and has an integrated digital video recorder. The camera offers a very sharp and stable image
with night vision and the technology used improves the image quality even further. The system uses digital wireless
technology and is equipped with advanced frequency signal encryption capabilities, which reduce interference caused by
other applications using the 2.4 GHz frequency band. This digital technology ensures your privacy and allows you to use
it over an extra long distance. THE BEST THAT WIRELESS HAS TO OFFER.
The monitor and camera are paired by factory default already. When adding the additional camera SEC-TRCAM40 (4
cameras max.) to the system, please refer to the section PAIRING for adding cameras.
Please note following:
1. When the alarm sounds press the "Delete" button to stop the alarm.
2. The Harddisk/SD devices do not support hot plugging
3. The monitor only accepts the SD card or harddisk devices with format Fat32. Users could format the SD card or
harddisk to Fat32 on computer.
4. Please properly format the SD card/Harddisk after long time use.
• We recommend that you read this manual before installing/using the camera system.
• Keep this manual in a safe place for future reference.
Packaging content:
1x camera with bracket
1x 7" monitor
2x antenna
1x AV output cable
2x AC/DC power supply
Technical specifications:
Camera:
Transmitting frequency:
Modulation:
Range:
Image chip:
Lens:
View angle:
Infrared illumination (LED):
Protection:
Microphone:
Working temperature:
Voltage:
Dimensions:
Weight:
LCD monitor:
Receiving frequency:
Channels:
ENGLISH
2.4-2.4835 GHz Digital
16QAM, QPSK, BPSK
Indoor ±50 m, open area ±150 m (depending on local conditions)
1/4" CMOS
2.0mm
73°
5 M
IP54
mono
-10°C ~ 50°C
5 V DC/400 mA
132x64x57mm (without bracket)
287 g (included cable)
2.4-2.4835 GHz Digital
4
2
