Technical data

Supply voltage:
Safety type:
Protective class:
Inputs:
Power suppy "POWER AC24V":
Enable "IN1":
Low level "IN2":
Conductivity sensor 2-wire "8 + 9":
Inductive sensor "1 ... 7":
Outputs:
24V AC-output "OUT AC24V":
24V DC-motor "DC-Motor + -":
24V AC-output "ALARM AC24V"
LED indicators
Front side:
At PCB:
"100%"-LED:
"OUT" -LED:
Control functions
Continuous mode:
Time control mode:
Conductivity mode:
Accuracy conductivity measuring:
Inductive mode:
2-wire mode:
Ambient temperature:
Dimensions:
Weight:
Because of the company's policy of continuous improvements to its products, the specifications may be changed
without notice.
417101373_Ecodos-PCB.docx
AC 24 V,15 W, 50-60 Hz
According to dosing units
III
Power supply via external transformer
(AC 24V, 15 W) (p/o unit)
5VDC-contact, not galvanic isolated (TTL)
5VDC-contact, not galvanic isolated (TTL)
"P120" probe (part no. 418811360)
Inductive probe (part no. 2874xx)
AC24V, max. 15W*, Triac
DC24V, speed controlled, max. 15W*
Alarm, AC24V, max. 15W*, Triac
*) total power consumption max. 15W
Operation indication (green)
Fault indication (red)
Concentration indicator
AC-Output indicator
Speed: app. 4 to 40 rpm
Delay: 0 to 63 sec.
Dosing time: 1 to 126 sec.
Speed: app. 4 to 40 rpm
Concentration range: 0 ... 25.2 mS/cm*
t max. 10 to 1260 sec
Speed: app. 4 to 40 rpm
*: In 2-wire probe w. probe P120
± 5% of value for conductivity
± 10% of value w. P120 probe
Max. 50°C
102 x 81 x 35 mm (W x D x H)
Approx. 0,1 kg
