Trouble shooting

Symptom
LED does not illuminate
when power is applied from
the dishwasher
Pump does not work /
solenoid valve not open at
conductivity mode
Green LED flashes
Red LED flashes
Red LED permanent on
(only at inductive mode)
417101373_Ecodos-PCB.docx

Possible cause

Transformer defective, wiring
defective
PCB defective
Measuring probe not connected
to PCB
Only in 2-wire mode:
DW filled with DEMI-water
(cond < 100µS/cm)
System in standby mode
Low level detection
No capsule inserted
Measuring probe not connected
Measuring probe defective
Max. dosage time exceeded
- 33 -

Corrective action

Check transformer, wiring and replace if
required
Replace PCB
Connect probe to "1 ... 7"
resp. "8 + 9"
Connect a wire link between "3" and "4"
ATTENTION: Metering starts the moment
dosing unit stands live and conductivity <
setpoint
Press QUIT button for 2 seconds to return in
operation mode (see also Chapter 4.4)
Replace container
Insert capsule
Connect inductive probe
Replace inductive prob e
Replace container/capsule
Check pump functionality
Check solenoid valve/water supply
