Pfannenberg PY X-M-05 Sicherheitshinweise / Kurzanleitung Seite 4

en
Electrical connection: (Circuit board in lower part)
PY X-M-05/ PY X-M-10/ PY X-L-15 (CPR)
AC:
DC:
Operating voltage connection
Setting the flash frequency
The flash frequency is set using the S1 switch on
the board in the lens, see table below.
1 Hz 0.75 Hz
*
0.5 Hz 0.1 Hz
* Factory setting
02/2022
Quick guide PY X-M(A)-05/ PY X-M(A)-10
AC version
Volume control Tone selector switch
AC:
DC:
Operating voltage connection for Operating voltage connection
sounder for flashing light
S2/ S3: Setting for common/ separate control of the light/ sounder component
(see digital operating instructions,
Setting the tone types (PY X-MA-05 and PY X-MA-05)
S1 switch setting on the connection board in lower part should be as follows:
2 Sawtooth
DIN 33404-3
9
(emergency signal)
Alternating tone
131
UK BS5839-1,
Level crossing fire alarm
160 Continuous tone (horn)
* Factory setting
PY X-MA-05/ PY X-MA-10/ PY X-LA-15
Volume control
Tone
selector
switch
www.pfannenberg.com/manuals)
161
162
163
164
4/10
PY X-L-15/ PY X-LA-15
DC version
AC:
DC:
Operating voltage Operating voltage
connection for connection for flashing
sounder light
Continuous tone
Interrupted tone
Interrupted tone
Slow whoop
*
086050003
