This display can be operated with the neo-
Remote handlebar controls as well as with
the touch screen display with three softkeys.
Display Screens:
The display has three screens: the home
screen, the power screen and the trip screen.
With the Set button on the neoREMOTE
handlebar control, you can switch between
these screens or alternatively use the Back
button on the touchscreen to return to the
previous screen. Depending on the settings,
changing display properties may not be
possible while moving. By pressing the
Home button you can return to the main
screen at any time.

MAIN SCREEN

The main screen shows the time, speed,
range and level of assistance as well as symbols
for the lighting or pushing aid (if active).
TRIP DISPLAY
16
All information of the main display remains
visible in the trip display. The speed display
is slightly smaller, below this, additional
indicators for distance (TRIP KM) and travel
time (TRIP TIME) appear.

POWER DISPLAY

Here the speed display becomes smaller again,
and a bar display is added for the ratio of
pedaling power (left) to motor support (right)
Walk Aid
and displays the average calculated calorie
Lighting
consumption (KCAL) and cadence (RPM).
Time
BATTERY – INSTALLATION, RE-
Speed
MOVAL
Battery Status
Assist
To insert the battery, open the battery lock if
necessary. Turn the key counterclockwise until
to the stop, the lock is now open. Position the
lower end of the battery in the battery rail and
rotate the battery fully into the socket. Lock the
lock and carefully remove the key. To remove
the battery, unlock the battery lock.
Odometer*
Trip Time*
*since the
last reset
Calories
Power
Cadence
