Key features
•
Clones bootable hard drives without PC (stand-alone)
•
Supports 2.5" and 3.5" SATA I/II/III drives
•
RGB bottom & display for cloning process
•
USB 3.0 Type-A or Type-C® with up to 5 Gbit/s to the host computer
•
SINGLE Mode – the computer recognises 2 independent drives
•
Plug & Play and HotSwap
•
LEDs for power & access
•
Supports Windows®, macOS® and Chrome OS™
Installation
1.
Plug the power adapter into the Docking & CloneStation and into a household
~230 V EU power outlet.
2.
Then plug the USB combo cable into the Docking & CloneStation and into a
suitable USB 3.0 Type-A or Type-C® port on your host computer.
3.
Now switch on the Docking & CloneStation using the ON/OFF switch. The power
LED starts to light up.
1.
Usage
SINGLE Mode
•
Carefully insert one or two SATA I/II/III drives.
Hint: You can insert one 2.5" or one 3.5" drive in each bay.
Bay 1
•
The SATA drive is automatically recognised by the operating system and is ready
for use immediately.
•
In SINGLE mode the SATA drives can be used independently of each other.
ATTENTION! As soon as one drive is already installed and a second drive is
added, both drives disconnect briefly and reconnect again.
Make sure that all read and write operations are completed to avoid data loss.
•
If the drive is not immediately recognised by the operating system, please check:
if the driver software is installed (USB).
if the SSD is initialised, partitioned and formatted.
Hint: The IB-127CL-U3 is backwards compatible with USB 2.0.
Note that the full USB 3.0 transfer rate of up to 5 Gbit/s can only be achieved with a
compatible USB 3.0 port on your host computer.
Manual IB-127CL-U3
ON
3.
OFF
Bay 2
2.
