A. Rotate the safety seat forward to the direction in which the vehicle is moving and
adjust the inclination position – position 4 is designed exclusively for Group 0. If the
child weighs less than 13 kg, it is necessary to leave the reduction cushion in the
safety seat.
B. Attach the ISOFIX Attachments by connecting them to the ISOFIX Guide Sleeves.
More information can be found in Chapter 8: ISOFIX ATTACHMENT
REMEMBER: Grab the entire safety seat fi rmly and make sure that it is properly
attached.
Next, take the 3-point vehicle seat belt and pull it through the vehicle seat belt routing
slot for Group 1 – forward-facing (see (01) Product Components Overview, element
17), put the vehicle seat belt through the guideways on the side of the 3-point seat belt
retraction system and next, pull the vehicle seat belt through the second guideway of the
safety seat and buckle the seat belt.
C. Grab the entire safety seat fi rmly and make sure that it is properly attached, also
make sure that the belts are not twisted anywhere
ATTACHMENT OF THE SAFETY SEAT FOR GROUP I
13
FORWARD TO THE DIRECTION IN WHICH THE VEHICLE IS MOVING –
A. Rotate the safety seat forward to the direction in which the vehicle is moving and
adjust the inclination position – position 4 is reserved exclusively for Group 0. If the
child weighs less than 13 kg, it is necessary to leave the reduction cushion in the
safety seat.
B. Take the 3-point vehicle seat belt and pull it through the vehicle seat belt routing
slot for Group 1 – forward-facing (see (01) Product Components Overview, element
17), put the vehicle seat belt through the guideways on the side of the 3-point
seat belt retraction system and next, pull the vehicle seat belt through the second
guideway of the safety seat and buckle the seat belt.
C. Grab the entire safety seat fi rmly and make sure that it is properly attached, also
make sure that the belts are not twisted
ATTACHMENT OF THE SAFETY SEAT FOR GROUPS II, III
14
FORWARD TO THE DIRECTION IN WHICH THE VEHICLE IS MOVING –
Rotate the safety seat forward to the direction in which the vehicle is moving and adjust
the inclination position to the most upright one – position 1. Remember to remove the
reduction cushion.
B. (!!!)---If the vehicle is equipped with the ISOFIX System---(!!!)
Attach the ISOFIX Attachment connecting them through the ISOFIX Guide Sleeves with
the. More information can be found in Chapter 8: ISOFIX ATTACHMENT.
3-POINT SEAT BELT
3-POINT SEAT BELT
