Installing the hook (Fig. 14)
The hook is convenient for temporarily hanging the tool.
You can install it on either side of the tool. It can be
removed without using any tool.
To install the hook, expand the upper part of the hook, and
insert it in the tool. To remove the hook, expand the upper
part of the hook in both directions and pull the hook from
the tool.
ASSEMBLY
CAUTION:
• Always remove the fuel cell and the battery cartridge
before carrying out any work on the tool.
Loading the nailer (Fig. 15)
Insert a strip of nails into the slit in the rear of the
magazine. (Fig. 16)
Pull the pusher lever with pressing the pusher button all
the way to the rear of the magazine. Then release the
pusher button, and return the pusher lever to the end of
the strip gently.
Removing nails (Fig. 17)
Pull the pusher lever and push the pusher button to
release the nail supporter, and then return the pusher
lever to the top with pushing the pusher button.
Slide the nails toward the rear of the magazine and
remove them out.
Nose adapter (Fig. 18)
The nose adapter prevents the surface of workpiece from
being scratched or damaged. Place the nose adapter
correctly.
Store the nose adapter in place when not in use. The
place for storage is on the bottom sides of the tool.
(Fig. 19)
Short nail adapter (Fig. 20 & 21)
Attach the short nail adapter to prevent the short nails
from being jammed when you use nails shorter than
25 mm (1").
Insert the short nail adapter into the slit in the rear of the
magazine. Then fix the adapter by tightening the bolt.
OPERATION
WARNING:
• Do not touch around the exhaust vent. The surface
will be very hot during or after an operation. Touching
around the exhaust vent may cause burns or injuries.
CAUTION:
• Make sure all safety systems are in working order
before operation.
Checking proper action before operation
Before operation, always check following points.
– Make sure that the tool does not operate only by
installing the battery cartridge and fuel cell.
– Make sure that the tool does not operate only by pulling
the trigger.
– Make sure that the tool does not operate only by
placing the contact element against the workpiece
without pulling the trigger.
– Make sure that the tool does not operate when pulling
the trigger first and then placing the contact element
against the workpiece.
Driving nails (Fig. 22)
1. To drive a nail, place the contact element against the
workpiece.
The fan motor is activated, fuel gas is injected into
combustion chamber and mixed with air by the fan.
(Fig. 23)
2. Hold the contact element pressing firmly and pull the
trigger.
Fuel gas is combusted and the nail is driven.
3. Further driving can be initiated only after both the
contact element and the trigger are released.
Anti dry fire mechanism
This mechanism prevents the tool from firing without nail.
Dry fire prevention automatically functions when the rest
of nails get to the last 9-11 pieces.
Jammed nailer
WARNING:
• Always be sure to remove the fuel cell and the battery
cartridge before clearing a jam.
CAUTION:
• Do not use deformed nails or nail strip. Failure to do so
causes poor nail feeding.
Follow the removing nail procedure and remove the nails
in the magazine. (Fig. 24)
Open the latch and release the door, then remove the
jammed nail.
MAINTENANCE
CAUTION:
• Always remove the fuel cell, the battery cartridge and
nails before attempting to perform inspection or
maintenance.
• Never use gasoline, benzine, thinner, alcohol or the
like. Discoloration, deformation or cracks may result.
Maintenance after daily work
Always check the tool for its overall condition and loose
screws before operation. Tighten as required.
At the end of daily work, conduct an end-of-workday
routine.
These simple steps are based on maintaining the safety
and performance of the tool.
Before leaving the work site:
• Remove the battery cartridge and store in a tool-
carrying case. Always use the tool-carrying case for
transporting and storing the tool.
• Dispose of all empty cells where they will not be found
by children, crushed, punctured or burned.
When you get home:
• Place the battery cartridge in its charger if it needs
charging as indicated by the red indication lamp.
• Wipe the tool with a clean, soft cloth.
