1.2.1. MPLH0MDS / MSLH0MDS, MPLHEMDS / MSLHEMDS

This manifold is available in brass chrome plated (MPL...) and stainless steel (MSL...). It consists of the follow-
ing components:
•
Pressure regulator with inlet pressure gauge, outlet pressure gauge and handwheel to regulate outlet
pressure
•
Option -S: 4-Port inlet shut-off valve
•
Relief valve
EN
•
Front plate and ground plate
•
Option –S: 4-Port Shut-off valve at outlet
SPECIALS
•
S: safety valve at outlet
•
C: check valves at inlets
•
U: safety valve at outlet and check valves at inlets

1.2.2. MPLH0MDP / MSLH0MDP, MPLHEMDP / MSLHEMDP

This manifold is available in brass chrome plated (MPL...) and stainless steel (MSL...). It consists of the follow-
ing components:
•
Pressure regulator with inlet pressure gauge, outlet pressure gauge and handwheel to regulate outlet
pressure
•
Option -P: Purge valves for process gas purging and 4-Port inlet shut-off valves at inlets
•
Relief valve
•
Front plate and ground plate
•
Option –S: 4-Port Shut-off valve at outlet
SPECIALS
•
S: safety valve at outlet
•
C: check valves at inlets
•
U: safety valve at outlet and check valves at inlets

1.2.3. MSLH0MDE MSLHEMDE

This manifold is only available in stainless steel. It consists of the following components:
•
Pressure regulator with inlet pressure gauge, outlet pressure gauge and handwheel to regulate outlet
pressure
•
Option -E: three 4-port purge valves each side for inert gas purging
•
Relief valve
•
Front plate and ground plate
•
Option –S: 4-Port Shut-off valve at outlet
SPECIALS
•
S: safety valve at outlet

1.3. EXPLANATION OF SYMBOLS

SAFETY INFORMATION
Safety information is highlighted by symbols in these instruc-
tions. This safety information is preceded by signal words that
define the extent of risk.
DANGER!
This combination of symbol and signal word indicates an im-
mediately dangerous situation that will cause death or severe
injury if not avoided.
WARNING!
This combination of symbol and signal word indicates a pos-
sibly dangerous situation that can cause death or severe injury
if not avoided.
BEWARE!
This combination of symbol and signal word indicates a pos-
sibly dangerous situation that can cause minor injury if not
avoided.
