2.5 Duty Cycle

The rated duty cycle of a Welding Power Source, is a statement of the time it may be
operated at its rated welding current output without exceeding the temperature limits of
the insulation of the component parts. To explain the 10 minute duty cycle period the
following example is used. Suppose a Welding Power Source is designed to operate at
a 40% duty cycle, 200 amperes at 18 volts. This means that it has been designed and
built to provide the rated amperage (200A) for 5 minutes, i.e. arc welding time, out of
every 10 minute period (40% of 10 minutes is 5 minutes). During the other 5 minutes of
the 10 minute period the Welding Power Source must idle and be allowed to cool. The
thermal cut out will operate if the duty cycle is exceeded.
100 100
90 90
80 80
70 70
60 60
MMA
50 50
40 40
30 30
Safe Operating Region
(TIG&MMA)
20 20
10 10
0 0
0 0
75 75 100 100
25 25 50 50
Welding Current(AMPS)

2.6 Packaged Items

◆2m Power cable
◆200 Amp Electrode Holder With 3m
◆300 Amp Earth Clamp With 3m
45
TIG
125 125 2 0 0
150 150 175 175 225 250 275 275
◆TIG Torch WP-17 4m
◆1.8m Gas Hose
◆Operating Manual

3.1 Layout For The Panel

Front
9 1
9 2
3 4
9 4
300
9 14
