IKA RCT digital Servicehandbuch Seite 3

Type: RCT digital
Voltage: 220 - 230 V~
Date: 10-OKT-2019
XXXXXXXXXX XXXXXXXXXXXXXXXXXXXX
Pos Item No Bezeichnung
215 25002243 Steckverbinder-Stecker
301 25004764 BLP RCT digital
401 25002070 Motor-EC
402 25002479 Auflage
403 25001385 Luefter
404 3460800 Gewindestift
405 3409300 Magnet
406 3416300 Zahnscheibe
407 25003722 Senkschraube
1704 4220200 USB Kabel
1810 1091500 H 11 (EURO)
1960 4049500 Schraubendreher
1996 3516800 PT 1000.60
2000 25004602 RCT digital Heizung komplett
®
IKA Service-Manual
XXXXXXXXXXXXXXXXXXXX
Description Technical data
connector male
230V
PCBA RCT digital
motor-ec
Support
fan
hexagon sock.set screw M 4,0x 6
Magnet AlNiCo
toothed lock washer V 4,3
countersunk head screw M3,5
USB cable
H 11 (EURO)
screw driver
PT 1000.60
RCT digital heating 230V complete 230V
Bemerkung
Pos 201, 202, 203, 204, 205, 206, 207, 208, 209, 210, 211, 212, 213, 214, 215
Item No.:0025004601
SZ: 12000020998
Remark
2 / 2
