Motherboard L Motherboard L
Motherboard L Motherboard Layout Motherboard L
1 PS2_USB_PW1 Jumper
2 ATX 12V Power Connector (ATX12V1)
3 CPU Heatsink Retention Module
4 AM2 940-Pin CPU Socket
5 CPU Fan Connector (CPU_FAN1)
6 2 x 240-pin DDRII DIMM Slots
(Dual Channel A: DDRII_1, DDRII_2; Yellow)
7 2 x 240-pin DDRII DIMM Slots
(Dual Channel B: DDRII_3, DDRII_4; Orange)
8 Infrared Module Header (IR1)
9 Game Port Header (GAME1)
10 Floppy Connector (FLOPPY1)
11 Primary IDE Connector (IDE1, Blue)
12 Flash Memory
13 Primary SATAII Connector (SATAII_1, Red)
14 Chassis Fan Connector (CHA_FAN1)
2 2 2 2 2
ASRock
manuals search engine
ayout ayout
ayout ayout
15 USB 2.0 Header (USB6_7, Blue)
16 System Panel Header (PANEL1)
17 USB 2.0 Header (USB4_5, Blue)
18 Chassis Speaker Header (SPEAKER 1)
19 Secondary SATAII Connector (SATAII_2, Red)
20 NVIDIA Single Chip
21 Clear CMOS Jumper (CLRCMOS1)
22 HDMR Slot (HDMR1)
23 Front Panel Audio Header (HD_AUDIO1)
24 PCI Express x1 Slot (PCIE2)
25 Internal Audio Connector: CD1 (Black)
26 PCI Slots (PCI1- 2)
27 PCI Express Graphics Slot (PCIE1)
28 ATX Power Connector (ATXPWR1)
29 Serial Port Connector (COM1)
AM2NF6G-VSTA Motherboard
