7-13-1 Replacing the Opto Sensors

1. Remove the Gearshift Assy.
2. Disengage the connector from the assy.
3. Remove 1off pozi head screw (M3x6). and remove the Opto Sensor.
Opto Sensor
Connector
4. Reassemble in reverse order.
(see 7-13 page 93)
Pozi head screw (M3x6)
Opto Senso r
Page 94
