- Seite 1 This document has been downloaded from: The largest resource for amusement machines documentation on the world wide web!
- Seite 2 NINJA ASSAULT DX OPERATORS MANUAL T IS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN CUSTOMER SAFETY AT ALL TIMES AND IT IS IMPERATIVE THAT THE DETAILS SET OUT IN THIS MANUAL ARE FOLLOWED PRECISELY Part No. 90500120 Issue 1...
- Seite 3 Page 2...
- Seite 4 Contents ΕΞΕΤΑΣΗ ΓΕΝΙΚΗΣ ΑΣΦΑΛΕΙΑΣ ......................Page 3...
- Seite 5 SAFETY WARNING GENERAL SAFETY CONSIDERATIONS Page 4...
-
Seite 6: Removing And Replacing Parts
Do not make any alteration to this equipment without prior approval. Doing so could cause unforeseeable danger. Only parts specified by Namco Europe Ltd. should be used when replacing parts. (Including screws) Ensure that the power to the equipment is turned OFF before commencing any maintenance work. - Seite 7 SICHERHEITSHINWEISE ALLGEMEINE SICHERHEITSHINWEISE Page 6...
-
Seite 8: Aus- Und Einbau Von Komponenten Und Teilen
HINWEISE ZUR AUFSTELLUNG 1m60cm or more Play Zone Pathway AUS- UND EINBAU VON KOMPONENTEN UND TEILEN Page 7... - Seite 9 SIKKERHEDS ADVARSEL SIKKERHEDSREGLER GENERELLE SIKKERHEDSOVERVEJELSER Page 8...
- Seite 10 PUNKTER OM INSTALLATION 1m60cm or more Play Zone Pathway Maskinen er smurt med olie for at gøre den lettere bevægelig. Pas på når maskinen flyttes på en skrå overflade. Hoved sektionens forreste center er meget tung, det er derfor vigtigt, at mindst 2 personer benyttes til at montere el.
- Seite 11 AVISOS DE SEGURIDAD. NOTAS DE SEGURIDAD. Page 10...
- Seite 12 NOTAS DE INSTALACIÓN. 1m60cm or more Play Zone Pathway RETIRAR Y REEMPLAZAR PARTES Y UNIDADES Page 11...
-
Seite 13: Consignes Generales De Securite
REMARQUES SUR LA SECURITE CONSIGNES GENERALES DE SECURITE Page 12... - Seite 14 NOTES D’INSTALLATION 1m60cm or more Play Zone Pathway DEPLACER ET REMPLACER LES UNITES ET LES PIECES DETACHEES. Page 13...
- Seite 15 Καθώς αυτές οι πληροφορίες σε αυτ το εγχειρίδιο έχουν δοθεί µε καλή πίστη και ακριβώς την ώρα της τύπωσης , η εταιρεία NAMCO EUROPE LIMITED κρατάει το δικαίωµα να κάνει οποιεσδήποτε αλλαγές χωρίς ειδοποίηση. Τα µηχανήµατα έχουν κατασκευαστεί σύµφωνα µε τους ρους της Ευρωπαϊκής Κοιν τητας , και έχουν ελεγχθεί σύµφωνα µε τους ν µους...
- Seite 16 1m60cm or more ΣΗΜΕΙΩΣΕΙΣ ΓΙΑ ΤΗΝ ΕΓΚΑΤΑΣΤΑΣΗ ΠΟΤΕ να µην αν βει το µηχ νηµα ε ν δεν χει ολοκληρωθε η εγκατ σταση. Για την αποφυγ ηλεκτρικ ν σοκ πρ πει το µηχ νηµα να χει γειωθε . Για την αποφυγ βλ βης στο µηχ νηµα λ γο λ θος λειτουργ ας , πρ...
- Seite 17 AVVERTENZE PER LA SICUEZZA NOTE PER LA SICUREZZA CONSIDERAZIONI GENERALI SULLA SICUREZZA Page 16...
- Seite 18 NOTES D’INSTALLATION 1m60cm or more Play Zone Pathway RIMOZIONE E SOSTITUZIONE DI GRUPPI E PARTI STACCATE Page 17...
-
Seite 19: Vanlige Sikkerhetstiltak
Sikkerhets advarsel. Sikkerhets beskjeder. VANLIGE SIKKERHETSTILTAK Page 18... - Seite 20 MERKNADER VED INSTALLASJON 1m60cm or more Play Zone Pathway FJERNE OG UTSKIFTE ENHETER OG DELER. Page 19...
-
Seite 21: Algemene Veiligheidsoverwegingen
Veiligheidsopmerkingen Veiligheidsopmerkingen ALGEMENE VEILIGHEIDSOVERWEGINGEN Page 20... - Seite 22 Opmerkingen aangaande Installatie 1m60cm or more Play Zone Pathway Verwijderen en vervangen van Assemblies en onderdelen Page 21...
-
Seite 23: Avisos De Segurança
AVISOS DE SEGURANÇA AVISOS DE PERIGO Page 22... - Seite 24 NOTAS SOBRE A INSTALAÇÃO 1m60cm or more Play Zone Pathway SUBSTITUIÇÃO E MONTAGEM DE PEÇAS Page 23...
- Seite 25 SÄKERHETS VARNING ALLMÄNNA SÄKERHETSBEAKTANDEN Page 24...
- Seite 26 1m60cm or more Play Zone Pathway ATT TA BORT ELLER BYTA UT ENHETER OCH DELAR Page 25...
-
Seite 27: Yleiset Turvallisuunäkökodat
Turvallisuusvaroitus Turvallisuusohjeet YLEISET TURVALLISUUNÄKÖKODAT Page 26... - Seite 28 ASENNUSHUOMIOITA 1m60cm or more Play Zone Pathway Page 27...
-
Seite 29: Accessories
1. SPECIFICATIONS POWER SUPPLY:- 230v/ 260watts AC AMBIENT OPERATING +5°C to +25°C TEMPERATURE MONITOR:- Toshiba 50” Projection Monitor COIN ACCEPTOR:- Mars CashFlow - 1 Channel DIMENSIONS:- Assembled 1110(w) x 1880(d) x 2140(h) Monitor Cabinet 1110(w) x 715(d) x 1700(h) Gun Assembly 590(w) x 1280(d) x 1050(h) Header Assembly... -
Seite 30: How To Play
2. HOW TO PLAY • • • • • • • • • • • • • •... -
Seite 31: Major Components
3. MAJOR COMPONENTS Rear Front Toshiba Projector Display Panel Speaker Assy Display Panel Mains-In Assy Schaffner Assy Play Panel Gun Assy NAOMI Game PCB Assy PSU Assy Coin Assy Gun Cabinet... -
Seite 32: Moving The Machine
4. MOVING THE MACHINE 5. INSTALLATION... - Seite 34 ΤΟ ΜΗΧΑΝΗΜΑ ΕΙΝΑΙ ΣΧΕ∆ΙΑΣΜΕΝΟ ΓΙΑ ΧΡΗΣΗ ΣΕ ΕΣΩΤΕΡΙΚΟ ΧΩΡΟ ΜΟΝΟ ΜΗΝ ΤΟΠΟΘΕΤΗΣΕΤΕ ΤΟ ΜΗΧΑΝΗΜΑ ΣΤΟΥΣ ΑΚΟΛΟΥΘΟΥΣ ΧΩΡΟΥΣ Εξωτερικά Απευθείας στον ήλιο,σε µέρη που υπάρχει υγρασία ή σκ νη,µέρη που υπάρχει άφθονο νερ ,κοντά σε air-condition ή άλλου είδους θέρµανση,µέρη µε υπερβολική υψηλή...
- Seite 36 5-1 Fitting the Header and Speaker Assemblies The fitting position of the Header Assembly is very high, and it is important that a means of reaching the height safely , without stretching, is available (e.g. steps, step stool etc.) Remove 4off Button head screw (M5x12) and remove the Top Cover. Top cover Button head screw (M5x12) Button head screw (M5x12)
- Seite 37 Washer Front display Header box Security screw (M5x12) Rear display Security screw (M5x12)
- Seite 38 Hex head screw (M6x30) Speaker assy Connector Retaining bracket...
- Seite 39 Bracket Gun stand Assy Hex head screws (M8 x 30) Shipping position of bracket Bracket Hex head screws (M8 x 30) Monitor cabinet Assy Gun cabinet Assy Brackets Connectors Hex head screws (M8 x 40)
- Seite 40 Lock Nut Level Adjuster Castor Note: If the location site of this machine has a polished floor it is recommended that rubber pads are fitted under the level adjusters to prevent the machine sliding on the floor when in use.
- Seite 41 6. ADJUSTMENTS Μετατροπές ή επιδιορθώσεις στα µηχανήµατα πρέπει να γίνονται µ νο απ εξουσιοδοτηµένα άτοµα.
- Seite 42 COIN COUNTER 2 Amp Q/B (Coin Fuse) PLAYER 1 ENTER SELECT DOWN TEST SERVICE...
- Seite 43 MENU COIN OPTIONS Used to set the price of play. GAME OPTIONS Used to set the game options. I/O TEST Used for testing switches and lamps. MONITOR TEST Used for adjusting the monitor. SOUND TEST Used to adjust the sound. ADS DATA Displays and resets bookkeeping data.
- Seite 44 COIN OPTIONS [DEFAULT IN GREEN] GAME COST 1 COIN (S) 1 CREDIT CONTINUE COST 1 COIN (S) 1 CREDIT FREE PLAY EXIT SELECT SW : CHOOSE ENTER SW : ENTER Note:- The price of play on this machine is set within the Cashflow Coin Mech. Ensure that the Game Cost is set to 1 Coin 1 Credit.
-
Seite 45: Game Options
GAME OPTIONS [DEFAULT IN GREEN] GAME DIFFICULTY C(MEDIUM) OFFICIAL RANKING MESSAGE ON HI-SCORE INITIALIZE EXIT SELECT SW : CHOOSE ENTER SW : ENTER e t I i r c c i f y t l i t i i l a i t i i l a... - Seite 46 GUN INITIALIZE SWITCH TEST LAMP & RECOIL TEST EXIT SELECT SW : CHOOSE ENTER SW : ENTER I/O TEST I/O PCB CHECK I/O PCB : Connect OK namco ltd.;JYU-PCB;Ver1.00;JPN, 1Coin 2Guns EXIT SELECT SW : CHOOSE ENTER SW : ENTER...
- Seite 47 I/O TEST GUN INITIALIZE MENU GUN INITIALIZE (1P) GUN INITIALIZE (2P) EXIT SELECT SW : CHOOSE ENTER SW : ENTER GUN INITIALIZE (1P) SHOOT AT SCREEN TO CHECK GUN ACCURACY PUSH ENTER SW:ADJUST GUN SIGHT UP SELECT SW ENTER SW : EXIT...
- Seite 48 GUN INITIALIZE (1P) AIM AT CENTER OF THE CROSS AND PULL GUN TRIGGER GUN INITIALIZE (1P) AIM AT CENTER OF THE CROSS AND PULL GUN TRIGGER Rear sight 10cm approx Line of Sight...
- Seite 49 I/O TEST SWITCH TEST [ON:RED] COIN SERVICE TEST SELECT(UP/DOWN) OFF/OFF ENTER START BUTTON(1P) START BUTTON(2P) GUN TRIGGER(1P) GUN TRIGGER(2P) UP SELECT SW ENTER SW : EXIT...
- Seite 50 I/O TEST LAMP & RECOIL TEST LAMP TEST START BUTTON(1P) LAMP ON START BUTTON(2P) LAMP ON RECOIL TEST PULL BOTH GUN'S TRIGGERS TO CONFIRM ACTION. EXIT SELECT SW : CHOOSE ENTER SW : ENTER...
-
Seite 51: Monitor Test
MONITOR TEST GRADATION PATTERN CROSSHATCH PATTERN (CRT) CROSSHATCH PATTERN (PROJECTOR) WHITE WINDOW (H) WHITE WINDOW (M) WHITE WINDOW (L) INTERLACE PATTERN VIEW ANGLE ADJUST (CRT) VIEW ANGLE ADJUST (PROJECTOR) FULL WHITE EXIT SELECT SW : CHOOSE ENTER SW : ENTER... -
Seite 52: Sound Test
SOUND TEST [DEFAULT IN GREEN] VOLUME ALL SP (0~127) ATTRACT (0~127) REQUEST SONG NO. MESSAGE ********** EXIT SELECT SW : CHOOSE ENTER SW : ENTER SERVICESW : REQUEST ON/OFF... - Seite 53 OTHERS [DEFAULT IN GREEN] ROM Ver. 00/09/20 WED 15:15:59 CLOCK --/--/-- --:--:-- 000000- 123456 LANGUAGE PAUSE NAOMI TEST MODE BACKUP MEMORY INITIALIZE EXIT SELECT SW : CHOOSE ENTER SW : ENTER...
- Seite 55 7. MAINTENANCE Μετατροπές ή επιδιορθώσεις στα µηχανήµατα πρέπει να γίνονται µ νο απ εξουσιοδοτηµένα άτοµα. Να είναι σίγουρα κλειστ το ρεύµα πριν οποιαδήποτε δουλειά στο µηχάνηµα.
- Seite 57 Washer Front display Header box Security screw (M5x12) Header box Security screw (M5x12) Security screw (M5x12) Font panel...
- Seite 58 Play Panel Vac-Form Security screw (M5x12) Security screw (M5x12) Connector...
- Seite 59 Play Panel Vac-Form Lamp (12v 2.2w) MicroSwitch FastOn terminals Note: Ensure that the wires are replaced to the correct terminal.
- Seite 60 Note: Take care not to lose the shakeproof washer under the Earth Terminals. Gun Assy Play Panel Connector Cover Whizz Nut (M6) Shakeproof Washer Earth Terminals Whizz Nut (M6) Connector Play Panel (rear) Note: Ensure that the shakeproof washer is refitted under the Earth Terminals.
- Seite 61 Hexagon cap nut (M4) Cap bolt (M3 x 10) Gun slide (L) Button bolt (M4 x 25) Cap bolt (M3 x 10) Gun slide (R)
- Seite 62 Hexagon cap nuts (M4) Button screw (M4 x 25) Gun casing (L) Lens Button screw (M4 x 10) Gun casing (R) Button screws (M4 x 10) Cap screw (M3 x 10) Ensure that the flat face of the lens is facing the back of the gun).
- Seite 63 Solenoid Cap bolt (M3 x 10) Solenoid bracket Connector Earth Shakeproof washer terminal Cap screw (M) (M3 x 8) Cap screws (M) (M4 x 6) Nut (nominal dia.16) Slide guide Solenoid Plunger...
- Seite 64 Note: When reassembling match the D-type hole of the solenoid bracket to the D shape of the solenoid and ensure that the ‘E’ ring and spacers are in the correct positions. Solenoid Spacers Slide guide Solenoid bracket Plunger E-ring Harness exit (downwards) Microswitch Blue wire.
- Seite 65 Fast-On terminals (microswitch) Earth terminal Connector (solenoid) Button screw (M4 x 10) Connector (sensor) Button screw Connector cover (M4 x 10) Gun casing (L) Earth terminal Connector Tube...
- Seite 66 8. PARTS 8-1 Header Assembly i t c i t c i t c i t c c i t Page 65...
- Seite 67 (Opposite side) Screen side Rear Projector Base interior drawing...
- Seite 68 e l l " 0 ½ "...
- Seite 69 P C B P C B (Opposite side) (Opposite side) Game PCB and PSU Assy (see 8-7 page 74 for details)
- Seite 73 u l l i l e...
- Seite 74 c t i c t i...
- Seite 75 8-7 PCB and Power Supply Assemblies c t i i f i t t i c t i c p i l Page 74...
- Seite 76 9. SCHEMATIC PLAY PANEL GUN ASSY (1P) HEADER ASSY GUN CONSOLE SOL_RET J36 MINI J37 MINI SOLENOID ASSY S_OUT J38 EI TRIGGER SENSOR PCB ASSY J29 MINI FLUORESCENT ASSY Yellow / White SOL24v GUN ASSY (2P) Yellow J27 EI SOL24v White / Red SIN5v White / Brown...
- Seite 77 Copies of Namco Game Manuals can be downloaded from our website: www.namco.co.uk under Components Distribution For all Parts or Technical Support contact: Brent Spares, Namco House, Units 5-8, Acton Park Estate, The Vale, London. W3 7QE www.namco.co.uk For Technical Support, Warranty and...
