7-1-2

Removing Jammed Cards

• Make sure that the Card Reader/Writer is not operating when removing
jammed cards.
1. Open the Card Reader/writer door.
2. Pull out the Card Reader/Writer slowly, and pull the finger grip forward to open
the Card Reader/Writer.
Release
Latch
3. Remove the jammed card.
Protusion
• If dust or other material other than the card is stuck, remove it thoroughly
and clean the head.
• Be careful not to bend the protusion.
4. Pull the finger grip forward when closing the Card Reader/Writer.
5. Push the Card Reader/Writer back, and close the door.
Card Reader/Writer
Card
(see 7-1 -1 page 75).
Page 76
