Buttons and functions

4 5 6 7 8 9
3
2
1
1. Open window function button
2. Programme selector button
3. Standby button
4. On/off (standby) indicator light
5. Heating mode indicator light
6. Open window function indicator light
7. Comfort mode indicator light
8. ECO mode indicator light
9. Timer mode indicator light
10. Display
11. Button to increase the value while making settings
12. Button to decrease the value while making settings
13. Timer settings button
14. Main power switch
Installation
The panel heater must be installed in a location
at least 30 cm away from the closest object.
Use the wall bracket as a template and mark out
where you need to drill on the wall. Use fasteners
suitable for the surface material and ensure that
there are no electrical wires or water pipes in
the wall where you intend to drill/screw.
10
11
12
13
5
14
