4. Preparing the Remote Controller

Lift the antennas
Remove the sticks
Rotate to attach the sticks
Ensure the control sticks are firmly mounted.
In real operation, the DJI Pilot app will prompt to warn that the transmission signal is
weak, and please adjust the antennas to ensure that the aircraft is back to the optimal
transmission range.
6
80°
The optimal transmission range is shown above.
Ensure the antennas are facing towards the aircraft.
When the angle between the antennas and the
back of the Smart Controller is 80° or 180°, the
connection between the Smart Controller and the
aircraft can reach its optimal performance.
The illustrations above show situations where the
operator and aircraft are far away.
