5. Care and Maintenance
Danger – risk of death from electric shock
Disconnect the mains plug from the socket before starting any cleaning work.
Warning - risk of cutting on the cutting rollers
Do not touch the cutting rollers.
Warning - damage to the device from moisture
Ensure, when cleaning, that no moisture penetrates the device in order to avoid
irreparable damage to it.

5.1 Emptying the container

• Switch the device off - as described in 4.2 Switching the device off - and disconnect
the mains plug.
• Lift the device head (1) off the waste paper basket.
• Empty the waste paper basket.
• Place the device head (1) back on the waste paper basket.
• Reconnect the device - as described in 3. Installation/Setup - to the power supply.

5.2 Cleaning the device

• Switch the device off - as described in 4.2 Switching the device off - and disconnect
the mains plug.
• Clean the device with a dry cloth. In cases of heavy soiling, the cloth can be dampened
a little.
• Allow the device to dry completely afterwards.
• Reconnect the device - as described in 3. Installation/Setup - to the power supply.
5.3 Cleaning / oiling the cutting rollers
Note
• Oil the cutting rollers after each emptying of the waste paper basket in order to
prolong the shredder's service life.
• You can nd an appropriate selection of cleaning products at
www.hama.com.
• Switch the device on - as described in 4.1 Switching the device on.
5.3.1 Cleaning with Hama cleaners for shredders (item number: 113820)
• Apply the Hama cleaner for shredders (item number: 113820) in several strips onto a
piece of DIN A4-size paper.
• Insert the paper into the centre of the intake shaft (3).
• Once the cutting process is complete, the device is ready for operation again.
5.3.2 Cleaning with cleaning paper
• Insert the cleaning paper into the centre of the intake shaft (3). The cutting rollers switch
on automatically.
• Once the cutting process is complete, the device is ready for operation again.
6. Troubleshooting
Error Possible cause
The connecting cable
(9) is not connected
The cutting rollers do
correctly.
not switch on in the "I"
position (6). The socket is not live.
The device is faulty.
The device switches itself
off after a prolonged The device has become
period of use and cannot too hot.
be switched back on.
7. Technical data
Input voltage
Mains Frequency
Max. power consumption
Dimensions (W x H x D)
Weight (net)
Weight (gross)
Max. noise level
Max. cutting performance - paper (70 gsm)
Max. cutting performance - paper (80 gsm)
Max. cutting speed
Max. feed width for paper / plastic cards
Cutting Size (Paper)
Max. constant operation time
Nominal idle period
Protection class (as per DIN 66399)
Safety levels (as per DIN 66399)
* Thicker paper, moisture or any voltage other than that permitted may reduce the
performance.

8. Warranty Disclaimer

All of the technical information, data and instructions regarding operation contained in
these operating instructions was up to date at the time of printing and is provided based
on previous experience and to the best of our knowledge.
Hama GmbH & Co KG assumes no liability and provides no warranty for damage resulting
from improper installation/mounting, improper use of the product or from failure to observe
the operating instructions and/or safety notes.
Remedy
Ensure that the mains
plug is in the mains
socket.
Check the domestic fuses.
Notify Customer Services.
Switch the device off and
allow it to cool down for
at least 30 minutes.
220-240 V~
50 Hz
184 W
30.8 x 10.6 x 6.3 cm
1100 g
1347 g
72 dB
6 sheets (DIN A4 paper)*
6 sheets (DIN A4 paper)*
3.0 m/minute
217 mm
8 mm
2 minutes
min. 30 minutes
1
P-1
7
