Electrical Safety; Intended Use; Technical Data; Noise/Vibration Information - Bosch Rotak 34 Originalbetriebsanleitung

10 | English

Electrical Safety

Warning! Switch off, remove plug from mains be-
fore adjusting, cleaning or if cable is cut, dam-
aged or entangled.
The blades continue to rotate for a few seconds
after the machine is switched off.
–
Caution do not touch the rotating blade.
Your machine is double insulated for safety and re-
quires no earth connection. The operating voltage is
230 V AC, 50 Hz (for non-EU countries 220 V, 240 V as
applicable). Only use approved extension cables. Con-
tact your Bosch Service Centre for details.
Extension cords/leads should only be used if they
comply with H05VV-F, H05RN-F types or IEC type de-
sign (60227 IEC 53, 60245 IEC 57).
If you want to use an extension cable when operating
your product, only the following cable dimensions
should be used:
2
– 1.0 mm : max. length 40 m
2
– 1.5 mm : max. length 60 m
2
– 2.5 mm : max. length 100 m
Note: If an extension cable is used it must be earthed
and connected through the plug to the earth cable of
your supply network in accordance with prescribed
safety regulations.
If in doubt contact a qualified electrician or the near-
est Bosch Service Centre.
WARNING! Inadequate extension cables can be
dangerous. Extension cable, plug and socket
must be of watertight construction and intended
for outdoor use.
It is recommended for increased electrical safety to
use a Residual Current Device (RCD) with a tripping
current of not more than 30 mA. Always check your
RCD every time you use it.
If the supply cord is damaged, it must be replaced by
a Bosch Service Centre.
For products not sold in GB:
WARNING: For your safety, it is required that the plug
attached to the machine is connected with the exten-
sion cord. The coupling of the extension cord must be
protected against splash water, be made of rubber or
coated with rubber. The extension cord must be used
with a cable strain relief.
The connection lead must be inspected for signs of
damage at regular intervals and may only be used if in
perfect condition.

Technical Data

Lawnmower
Article number
Rated power input
Blade width
Height of cut
Grassbox, capacity
Weight according to EPTA-Procedure 01/2003
Protection class
Serial number
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific coun-
tries, these values can vary.
Please observe the article number on the type plate of your garden product. The trade names of the individual
garden products may vary.

Noise/Vibration Information

Measured sound values determined according to 2000/14/EC (1.60 m height,
1 m distance away).
Typically the A-weighted noise levels of the product are:
Sound pressure level
Sound power level
Uncertainty K
Wear hearing protection!
Vibration total values (triax vector sum) determined according to EN 60335:
Vibration emission value a
Uncertainty K
F 016 L70 837 | (23.3.11)
h
Products sold in GB only: Your product is fitted with
a BS 1363/A approved electric plug with internal fuse
(ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it
should be cut off and an appropriate plug fitted in its
place by an authorised customer service agent. The re-
placement plug should have the same fuse rating as
the original plug.
The severed plug must be disposed of to avoid a pos-
sible shock hazard and should never be inserted into a
mains socket elsewhere.
Products sold in AUS and NZ only: Use a residual cur-
rent device (RCD) with a rated residual current of
30 mA or less.
Symbols
The following symbols are important for reading and
understanding the operating instructions. Please take
note of the symbols and their meaning. The correct in-
terpretation of the symbols will help you to use the
garden product in a better and safer manner.
Symbol Meaning
Movement direction
Wear protective gloves
Weight
Switching On
Switching Off
Permitted action
Prohibited action
Accessories/Spare Parts

Intended Use

The garden product is intended for domestic lawn
mowing.
3 600 H82 0..
W
cm
mm
l
kg
see type plate on the garden product
Rotak 34 Rotak 37
3 600 H82 1..
1300
34
–
20 70 20
40
11.0
II
/
3 600 ... H82 0.. H82 1..
dB(A) 83
dB(A) 93
dB =1
2
m/s <2.5
2
m/s =1.5
Bosch Power Tools
1400
37
–
70
40
11.2
II
/
84
94
=1
<2.5
=1.5
