Declaration of Conformity

We declare under our sole responsibility that the product described under "Tech-
nical data" is in conformity with the following standards or standardization docu-
ments: EN 60335 according to the provisions of the directives 2004/108/EC,
2006/42/EC, 2000/14/EC.
2000/14/EC: Guaranteed sound power level
Conformity assessment procedure according to Annex VI.
Equipment category: 32
Notified body:
SRL, Sudbury, England, Nr. 1088
Technical file at:
Bosch Lawn and Garden Ltd., PT-LG/EAE,
Stowmarket, Suffolk IP14 1EY, England
Dr. Egbert Schneider
Senior Vice President
Engineering
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
10.03.2011
Troubleshooting
STOP
Problem Possible Cause
Motor refuses to Power turned off
start
Mains socket faulty
Extension cable damaged
Fuse faulty/blown
Grass too long
Motor protector has activated
Garden product Extension cable damaged
functions
Internal wiring of garden product damaged
intermittently
Motor protector has activated
Garden product Height of cut too low
leaves ragged finish
Cutting blade blunt
and/or
Possible clogging
Motor labours
Blade fitted upside down
Blade not rotating Cutting blade obstructed
while garden prod-
uct switched on
Blade nut/bolt loose
Excessive Blade nut/bolt loose
vibrations/noise
Cutting blade damaged
After-sales Service and Customer
Assistance
www.bosch-garden.com
In all correspondence and spare parts orders, please
always include the 10-digit article number given on the
type plate of the garden product.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: +44 (0844) 736 0109
Fax: +44 (0844) 736 0146
E-Mail: boschservicecentre@bosch.com
Bosch Power Tools
Dr. Eckerhard Strötgen
Head of Product
Certification

Mounting and Operation

Action
Delivery Scope
Handle Assembly
Snap together the Grassbox
Grassbox fitting/removing
Adjusting the Cutting Height
Connecting the Extension Lead
Starting
Stopping
Working Advice
Blade Maintenance
Selecting Accessories
Corrective Action
Turn power on
Use another socket
Inspect cable, replace if damaged
Replace fuse
Increase height of cut and tilt garden prod-
uct to reduce starting load
Allow motor to cool and increase height of
cut
Inspect cable, replace if damaged
Contact Service Agent
Allow motor to cool and increase height of
cut
Increase height of cut
Replace the blade
Check underneath the garden product and
clear out as necessary (always wear garden-
ing gloves)
Refit blade correctly
Switch off garden product
Clear obstruction (always wear gardening
gloves)
Tighten blade nut/bolt (17 Nm)
Tighten blade nut/bolt (17 Nm)
Replace the blade
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: +353 (01) 4 66 67 00
Fax: +353 (01) 4 66 68 88
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: +61 (01300) 307 044
Fax: +61 (01300) 307 045
Inside New Zealand:
Phone: +64 (0800) 543 353
Fax: +64 (0800) 428 570
Outside AU and NZ:
Phone: +61 (03) 9541 5555
www.bosch.com.au
English | 11
3 600 ... H82 0.. H82 1..
dB(A) 94
Figure
1
2
3
3
4
5
5
5
–
5
7
8
