3. Layout, Connections & LED's

3.3 LED's

Status LED's:
LED Name
Link/Act 100
Link/Act 10
LAN TX
LAN RX

4. Hardware Installation

Because there are large differences between PC's and Networks, we can give you only
a general installation guide. Please refer your computer's reference manual whenever
in doubt.
1. Connect the EX-6032 with a normal patch cable (Crossover Cable not required).
2. Now you can connect your serial device to the 9-pin D-SUB connectors of the EX-
6032.
3. Connect the included power supply to the DC connector at the EX-6032 or connect
the optional power supply into the terminal block at the EX-6032.
© Copyright 2017 by EXSYS Vertriebs GmbH. All Rights Reserved
LAN TX LED
LAN RX LED
Color
Continuously on:
Green
Flash:
Continuously on:
Green
Flash:
Green Flash:
Green Flash:
Link/Act 100 LED
Link/Act 10 LED
LED Function
Connected in 100Mbps Mode
Transmit Data
Connected in 10Mbps Mode
Transmit Data
Transmit Data to LAN Port
Receive Data from LAN Port
18
