14 | English
Henk Becker Helmut Heinzelmann
Executive Vice President Head of Product Certification
Engineering PT/ETM9
Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
03.09.2014
Troubleshooting
STOP
Problem
Motor refuses to start
Machine functions
intermittently
Machine leaves ragged finish
and/or
Motor labours
Blade not rotating while garden
product switched on
Excessive vibrations/noise
F 016 L81 177 | (24.9.14)

Mounting and Operation

Action
Delivery Scope
Handle Assembly
Snap together the Grassbox
Grassbox fitting/removing
Adjusting the Cutting Height
Connecting the Extension Lead
Starting
Stopping
Working Advice
Blade Maintenance
Selecting Accessories
Possible Cause
Power turned off
Mains socket faulty
Extension cable damaged
Fuse faulty/blown
Possible clogging
Motor protector has activated
Mowing too low for the conditions
Extension cable damaged
Internal wiring of machine damaged Contact Service Agent
Motor protector has activated
Height of cut too low
Cutting blade blunt
Possible clogging
Blade fitted upside down
Cutting blade obstructed
Blade nut/bolt loose
Blade nut/bolt loose
Cutting blade damaged
Figure
1
2
3
3
4
5
5
5
5 – 6
7
7
Corrective Action
Turn power on
Use another socket
Inspect cable, replace if damaged
Replace fuse
Check underneath the garden product and clear out as
necessary (always wear protective gloves)
Allow motor to cool and increase height of cut
Increase height of cut
Inspect cable, replace if damaged
Allow motor to cool and increase height of cut
Increase height of cut
Replace the blade
Check underneath the garden product and clear out as
necessary (always wear protective gloves)
Refit blade correctly
Switch off garden product
Clear obstruction (always wear protective gloves)
Tighten blade nut/bolt (17 Nm)
Tighten blade nut/bolt (17 Nm)
Replace the blade
Page
178
178
178
178
179
179
179
179
179 – 180
180
180
