18 | English

Noise/Vibration Information

Noise emission values determined according to EN 50636-2-92.
Typically the A-weighted noise levels of the product are:
– Sound pressure level
– Uncertainty K
– Sound power level
– Uncertainty K
Vibration total values ah (triax vector sum) and uncertainty K determined according to EN 50636-2-92
– Vibration emission value a
h
– Uncertainty K

Mounting and Operation

Do not connect the product to the mains socket before
u
it is completely assembled.
Action
Delivery scope
Assembly
Connecting the extension cable
Assembling the grassbox
Grassbox assembly
Adjusting the working height
Switching On and Off UniversalRake
900
Switching On and Off UniversalVerti-
cut 1100
Maintenance, Cleaning and Storage

Working Advice

Raking/Verticutting
UniversalRake 900:
In case of overload, the speed of the motor drops and the
motor sound changes. In this case, stop, release the start/
stop lever and adjust to a higher working height. Failure to
do so could damage the machine.
F 016 L94 116 | (17.02.2021)
dB(A)
dB
dB(A)
dB
2
m/s
2
m/s
Figure Page
A 293
B 293
C 294
D 294
E 295
F 295
G 296
H 296
Place the product on the
edge of the lawn, as close to
the mains socket as pos-
sible. Work away from the
mains socket.
Position the cable to oppos-
ite side (already raked/ver-
ticut lawn) at the end of
each turn.
When raking/verticutting do
not overload the motor.
3 600 H8A 0..
81
= 2.5
94
= 1.0
4.0
= 1.6
UniversalVerticut 1100:
The motor is protected by a safety cut out, which is activated
when the blades become jammed, clogged or if the motor is
overloaded. When this occurs, switch the product off.
The safety cut out is only reset when the start/stop lever is
released.
Pull the mains plug, remove any blockages and wait one
minute before restarting the product so that the safety cut
out can reset itself.
Always wear gardening gloves when handling or work-
u
ing near the sharp tines/blades.
Note: When waiting for a reset of the safety cut out and actu-
ating the start/stop lever too early with the product plugged
into the socket outlet, the reset time of the safety cut out will
increase.
If the product cuts out again, increase the working height or
postpone use until conditions improve. Please refer to the
Trouble Shooting Chart" and "Raking/Verticutting Tips".
Raking/Verticutting Tips
Optimum conditions for raking/verticutting are when the
grass is short and slightly moist. Raking or verticutting the
lawn when the soil is very soft or hard can damage it and
cause the product to collect poorly.
– Kill moss with a commercially-available moss killer before
raking/verticutting.
– Start the product at the highest working height and lower
it as required.
– Rake/Verticut the lawn in the one direction, then proceed
at right angles a week later until the whole lawn has been
completed.
– Depending on the condition of the lawn, raking/verticut-
ting moss and dead plant parts can lead to ragged and
bare patches.
3 600 H8A 1..
80
= 2.5
94
= 2.0
2.9
= 1.5
