Please use the original packaging if the device is to be transported. Make sure that you pack the device in
the original state.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, lamp explosion, crash etc.
DESCRIPTION OF THE DEVICE
Features
Professional theatre spot
Rugged aluminum housing • Strong aluminum mounting bracket with hole for fixing the obligatory safety rope
• 4 clip-to-hold clamps with spring locks for comfortable opening of the color filter frame • Protective shield is
integrated in the tube • For extremely powerful CDM-T lamp • Ideal for theatres, exhibitions and mobil use
Overview
1
INSTALLATION
Installing/Replacing the lamp
3
5
2
4
DANGER TO LIFE!
Only install the lamp with the device switched off!
Unplug from mains before!
6
7
(1) Power cord with safety plug
(2) Fixation screw
(3) Mounting-bracket
(4) Housing
(5) Screws for protective shield
(6) Protective shield
(7) Clip-to-hold clamps for color
filter frame
14/18
00056134.DOC, Version 2.0
