Manual | Ladesäule Twin
Installation and operation
The described charger for electric vehicles is a product
that may only be connected by qualified electricians.
Specialists should have familiarized themselves with
the topic of electromobility and
the associated standards.
Any damage to the outer casing or the
charging cables or to insulation parts of the
charging socket could possibly lead to fire or
risk of injury to personnel. Regular checks and
careful handling of these devices will prevent
such risks. Please note that the prescribed
residual current circuit breakers for personal
protection must be installed in the pre-installation
or in the supply line of each charging point.
With some versions of the charging point, one or more RCDs
(RCD, 30mA or RCD 6mA) are also directly installed in the charging
device. Even in such cases the supply line, which can then be
a common line for two charging points, must be protected by miniature
circuit breakers LS (MCB) or ideally FI and LS (RCD + MCB).
Each charging point then also has its own FI (RCD, Type B or A+)
within the pole.
It is very important that the equipment and the housing parts are well
grounded. The earthing must be checked by a qualified electrician
during installation. Depending on the installation site, the necessary
measures for lightning protection must be evaluated If necessary,
additional lightning protection devices must be installed in the buildings
or the existing pre-installation.
7
Technische Änderungen unter Vorbehalt | Stand 03/2022 | DB9.0030
