Manual | Ladesäule Twin
Maximum current setting
Step by step
1.
Ensure that the power source is disconnected.
2.
Turn the rotary switch with a small srewdriver
to the correct position (see table).
3.
Close the cover.
4.
Enable the power source. The settings
will be active after a reboot of the
charger after a power-off.
5.
Connect the charger to the test-simulator or
a car which shows the current while charging.
6.
Control the settings with the real current.
LED display of the settings during
the boot sequence:The blue flashing
sequence shows the tens place,
the green flashing sequence shows
the ones place of the current.
z. B.
32 ampere = 3 long blue blinks and 2
short green blinks
15A = 1 x blue / 5 x green
Technische Änderungen unter Vorbehalt | Stand 03/2022 | DB9.0030
3 phase
1 phase
1 - 6A
2 - 7A
3 - 8A
4 - 9A
5 - 10A
6 - 13A
7 - 14A
8 - 15A
9 - 16A
9 - 16A
21
