4. NOTE: It is normal for the charging unit to become
warm (but not hot) during charging.
5. When the rechargeable battery is fully charged,
disconnect the charging unit from the power sup-
ply and charging socket (4a).
6. Fit the cover on the charging socket again (4).
Make sure it clicks into place properly.
9.4 Filling the spray bottle (Fig. 7)
1. Detach the spray bottle (9) from the spray head
(7).
2. Pour the cleaning agent into the bottle. The maxi-
mum capacity of the bottle is roughly 300 ml. Make
sure that you do not overfill the bottles.
NOTE: The product is only suitable for use with
a standard non-foaming window cleaning agent.
Always observe the dilution and concentration
instructions on the packaging of the appropriate
cleaning agent.
3. Wipe up spilled cleaning agent with a soft cloth
and reattach the spray bottle (9) to the spray head
(7).
9.5 Operating the atomiser nozzle (Fig. 8 + 9)
No spraying possible
Single jet
Spray jet
1. Turn the spray nozzle (7a) to single jet mode or
spray jet mode.
2. Press the trigger of the spray bottle (8) to spray
the cleaning agent from the spray bottle (9).
Note: It may be necessary to press the trigger sev-
eral times to spray cleaning agent the first time it
is used.
9.6 Switching on/off (Fig. 12)
• Switch on the product by pressing the on/off switch
(5).
• Press the on/off switch (5) again to switch the device
off.
28 | GB
9.7 Emptying the dirty water tank (Fig. 10 + 11)
WARNING! Switch off the product before removing the
dirty water tank (2)!
The liquid on the surface to be cleaned is collected in
the dirty water tank (2). Empty the dirty water tank (2)
when the water level has reached the maximum mark
(2g) (approx. 150 ml).
ATTENTION! The top and bottom tanks are not tightly
connected, so handle the product carefully and take
care to avoid spilling the liquid accidentally.
Removing the dirty water tank
1. Press the lock on the water tank (2a) down. The
dirty water tank (2) is lifted slightly. Remove the
dirty water tank (2) from the product.
2. To empty the dirty water tank, open the sealing
plug (2b), tilt the dirty water tank (2) and pour out
the dirty water.
Attaching the dirty water tank
1. Close the sealing plug (2b). Press the lock on the
water tank (2a) down.
2. Reinsert the dirty water tank (2). Make sure that
the dirty water tank (2) clicks into place.

10. Commissioning

m Attention!
Always make sure the product is fully assembled
before commissioning!
10.1 Operation (Fig. 13 + 14)
1. Fill the spray bottle (9) with water and cleaning
agent.
2. Set the spray nozzle (7a) to the selected jet type
and spray the water evenly onto the surface to be
cleaned.
3. Clean the surface with the microfibre cloth (6).
4. If necessary, spray again.
WARNING! Before each use, check the suction
attachment (1) for dirt residues that could scratch
the surface you intend to clean.
If the suction attachment is dirty, wipe it with a
clean, damp cloth.
5. Press the on/off switch (5) to switch on the product.
6.
