EX-1186HMVS-2
3. Layout & Connectors

3.1 Layout

7-24V T-Block for optional
external Power Supply
Power LED
7-24V DC-Jack for optional
external Power Supply

3.2 Connectors

+7V - 24V T-Block:
GND (Ground)
+7V - 24V
+7V - 24V DC-Jack:
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
4x USB 3.2 Gen 1
Downstream A-Port
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
ATTENTION!!!
Only for use with optionally available power supply!
9
English
1x USB 3.2 Gen 1
Upstream B-Port
