3. Layout & Connectors
3.2 Connectors
USB 3.2 Gen 1 A-Port:
StdB_SSTX +
StdB_SSTX -
VCC
USB 3.2 Gen 1 B-Port:
StdB_SSTX +
StdB_SSTX -
D-
D+

4. Hardware Installation

Because there are large differences between PC's, we can give you only a general installation
guide. Please refer
1. Install the EX-1185HMVS-2 on a DIN rail using the supplied DIN rail kit or on a wall using the
wall mounting bracket.
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
GND_DRAIN
StdB_SSTX+
StdB_SSTX -
GND
D- D+
GND_DRAIN
StdB_SSTX+
StdB_SSTX -
VBus
GND
your computer's
Mounting on DIN Rail
Attention!
Never plug in with force
or in wrong direction.
Attention!
Never plug in with force
or in wrong direction.
reference manual
Holes for Wall Mounting
10
EX-1186HMVS-2
whenever in doubt.
