Using Grommet

Tear off the cocks of grommets properly and pull up the grommet so that sealing can
wrap the cable properly as illustrated. If it doesn't wrap the cable properly,it could cause
the water leakage problem.

Using RJ45 Easy Cap for Network cable

Recommended cable length into the Junction box base

• CABLE with RJ-45 Connector: 70mm~80mm
• CABLE for Network Wiring Connector: 20mm~30mm (excluding cable tripping
section) 8P cable stripping distance: 20mm~30mm
• Power CABLE: 20mm~30mm (excluding cable tripping section) 8P cable stripping
distance: 20mm~30mm
