Part Names - Eneo ICB-72M2713MAA Schnellinstallationsanleitung

Part names

Sunshield bolt
Sunshield
Body Case
Dual window
Inside of Opening Cover
Micro SD Card slot
Junction Box Base
6
IP Reset (Default) : pressing
for 5~8 secondsresets all
parameters to original
factory settings.
User Network connector
Ethernet from Cam.
Network wiring Connector
Power/ Alarm
Junction Box Top
Bracket
Lock/Unlock Screw
Please close the cover
after setting up and
tighten it properly.
Otherwise, moisture
can get inside the
housing.
Grommet
Junction Box Base
Hinge Pin
Junction Box Open Alarm
Power & I/O from Cam.
