EX-1116HMVS

1. Description

The EX-1116HMVS is a USB 3.2 Gen 1 metal HUB for up to sixteen end devices. The hub is
equipped with 16 ports for end devices and 1 port for connection to PC. It supports all USB ports
from 1.1 to 3.2 and each USB port on the EX-1116HMVS is additionally screwable. Power supply
via DC-Connector or Terminal Block can provide 1,5A to each USB port. This allows you to charge
iPhones, iPads, smartphones and tablets without any problems. The USB 3.2 bus optimally sup-
ports the performance of the fast Genesys chipset. The EX-1116HMVS thus ensures secure data
transfer and excellent performance of up to 5Gbps. It supports only Self-Powered mode and thus it
is mandatory to connect an external power supply. In addition, the EX-1116HMVS is equipped with
15KV ESD surge protection. The EX-1116HMVS supports IP30 standard. The DIN-Rail kits includ-
ed in the scope of delivery are each screwed tight with two screws on the back and the mounting
angles are each screwed tight with three screws on the side.
Features:
•
Compatible for USB 1.1, 2.0 & 3.2
•
Up to 5Gbit/s
•
All Operating Systems are supported
•
All ports are Screw Lock
•
15KV ESD Surge Protection
•
Certificate for

2. Extent of Delivery

Before you connect the EX-1116HMVS to your PC, you should first check the contents of the deliv-
ery:
•
EX-1116HMVS
•
USB 3.2 Gen 1 Cable (screw lock) (EX-K1581V)
•
DIN-Rail Kit (EX-6095)
•
2x Mounting Angle
•
Manual
