Instructions for Use AssistX Call | 45
12. Technical Data
Dimensions: 74 mm x 74 mm x 27 mm
Weight: 100 g
IP Rating: IP 54
Power supply: via call system 6.5- 24V DC, if required: external
power supply via mini-USB, 5V DC, max.500mA with bridging of
power failure with LiPo battery min. 24h
Power consumption: max. 200 mA at 5V, max. 100 mA at 12V,
max. 50 mA at 24V, with ext. Power supply/battery backup max.
500mA
connection:
Switch connectors: 2x 3.5 mm jack plugs,
AssistX Port
Call system: for special cable to the nurse call system
