38 | Instructions for Use AssistX Call

8. Use of the device

is supplied with power via the call system or an external
AssistX Call
5V USB power supply unit. In both cases, depending on the call sys-
tem, the device also works in the event of a power failure in the net-
work. When powered by an external power supply unit, the built-in
4
lithium polymer battery guarantees full functionality for a few hours
in the event of a power failure.
Depending on the call system, the call line can be interrupted or clo-
sed for an adjustable time. The switching contacts are connected to
the call system using the cable that matches the call system.

Standard configuration:

In the standard configuration, switches the call contact
AssistX Call
for 1.5 seconds when the entrance sensor has been activated.
• Connect Sensors
Connect one or two sensors to sockets S1 and S2 as required.
1
