Instructions for Use AssistX Call | 39
• Establish connection
Establish the connection to the call system at the RJ45 modular
5
socket with the enclosed 8-pin cable.

Switching ON and OFF:

If the device is not required for a longer period of time, the electro-
nics can be switched off. The device switches on automatically when
it is connected via the USB socket or an external power supply is
connected through the call system.
To switch on, press the button for 2 sec. Release the button
2 2
LED lights up green. To switch off, press
after the tone signal, the
3
the button for 3 sec. Release after the tone signal. After the flas-
2
button LED turns red.
hing, the LED turns off, the
3 2
After the device has been switched on, the sensor inputs are che-
cked. The device automatically adjusts itself to the connected sen-
sors. If single sensors with a closing contact are plugged in, their
functionality must be checked. The LED in the button flashes until
3
each sensor with a closing contact has been actuated once. The call
release is suppressed for 20 sec during the test period.
