setting up your side-by-side
refrigerator
2. Removing the freezer door
A few things to mention first.
• Make sure that you lift the door straight up so the hinges are not bent or broken.
• Be careful not to pinch the water tubing and wire harness on the door.
• Place doors on a protected surface to prevent scratching or damage.
1. With the Freezer door closed, remove the upper hinge cover
disconnect the wires by gently pulling them apart
2. Remove hinge screws
the upper hinge
5
3. Next, remove the door from the lower hinge
7
6
4. Remove the lower hinge
All manuals and user guides at all-guides.com
1
3
and the ground screw
. Be careful that the door does not fall on you as you are removing it
5
4
3
8
using a hex wrench.
1
using a screwdriver, and then
.
2
2
4
by turning counter-clockwise, and take off
6
by carefully lifting the door straight up
Be careful not to pinch
the water tubing and
wire harness on the
door.
7
.
_11
