Before assembling, make sure the
battery is not inserted in its housing.
4.2 INSTALLATION / REMOVAL OF
THE BLOWER/VACUUM TUBE
Place the front blower/vacuum tube (Fig.3.A)
in the back blower/vacuum tube (Fig.3.B) and
secure it with the dedicated screw (Fig.3.C).

4.3 FITTING THE COLLECTION BAG

1. Connect the collecting bag (Fig.4.A) to the
outlet nozzle (Fig.4.B), making sure it is fitted
correctly.
2. Connect the collection bag to the front tube
(Fig.5.A) using the appropriate hook (Fig.5.B).

4.4 ASSEMBLING THE FRONT HAND GRIP

Place the hand grip (Fig.6.A) in its designated
location and fix it in the desired position using the
corresponding knob (Fig.6.B).

4.5 FITTING THE SHOULDER STRAP

Fasten the shoulder strap carabiner into the
dedicated eyelet (Fig.7.A) located on top of the
machine.
IMPORTANT Stop the machine and always
remove the battery (paragraph 7.2.2) each time
theblower/vacuum tube and the collection bag are
removed.

5. CONTROLS

5.1 VACUUM/BLOWER SWITCH

The switch allows the user to change the
machine's function:
– Setting the switch to "BLOW" (Fig.8.A)
activates the blowing function;
– Setting the switch to "VAC" (Fig.8.B) activates
the vacuum function;
The machine's function mode must be
set before it is switched on.

5.2 START/STOP SWITCH

The start/stop switch (Fig. 9) has a dual function:
1. it starts/stops the machine and, at the same
time, it engages/disengages the rotation of
the rotor;
To stop the machine, move the switch to the "0"
position.
2. This allows the rotation speed of the
rotor to be adjusted by turning the switch
into the desired position (1 to 5).
Starting the machine causes the
rotor to start rotating at the same time.

6. USING THE MACHINE

6.1 PREPARATION

6.1.1 Checking
(Fig.10)
Before each use, check the battery charge status
and recharge it by following the instructions in the
battery booklet.
6.1.2 Shoulder strap adjustment
Adjust the length of the shoulder strap
Adjust the length of the shoulder strap to allow
the vacuum tube to be placed very close to the
ground. (Fig.7).

6.2 SAFETY CHECKS

Always carry out the safety checks before
use.
6.2.1 General check
Object
Hand grips (Fig. 1.D, 1.E)
Screws on the machine
Cooling air ducts
Blower/vacuum tube.
(Fig. 1.B, 1.C) and
collection bag (Fig. 1.G)
Rotor
Guards
Battery (Fig. 1.K)
Start/stop switch (Fig.1.F)
EN - 6
and recharging the
Result
Clean, dry and fixed
firmly to the machine.
Correctly tightened
(not loose)
Not clogged
Correctly installed.
No signs of damage.
Not clogged.
No signs of damage
No signs of damage
No damage to the casing,
no liquid leakage
It must easily move from
one position to the other.
battery
