6. Tuner
6.1 Tuner Settings
• By default the Server box is in Dynamic mode.
• Server box tuned the client requested carrier in Dynamic mode.
• Once the Client is requested to lock the particular frequency. Then Server box tuned
that carrier in Dynamic mode.
• LNA used to attenuate the signal strength and quality.
32
ENGLISH
6. Tuner
Select „Static" for configure the tuner to the particular frequency where the client can
only tune that carrier.
• Source - To select DiSEqC 1.0 switch (A, B, C or D). The default value set to be 1.
• Frequency - To enter the fixed frequency.
• Symbol rate - To enter the fixed symbol rate(1000 to 65000 kps).
• Polarization - To select Horizontal / Vertical.
• Streaming Address - To enter the IP address and port number for multicast. Each
field values shall be 0 to 255. Port no range should be 1024 -65535.
• LNA - To attenuate the signal from 0 to 16db.
• PID's - To enter (PAT, PMT, Audio, Video, Subtitle, Audio Descriptor, Teletext...) PID's.
Maximum of 32 pids and no more duplication allowed.
