12. Technical Data

The Merida, certified in compliance with DIN-EN 13240 : 2001 + A2 2004 and Art. 15
a B-VG (Austria), can only be operated when the fire box is closed; more than one device
can be connected to the chimney.
VKF-No.: 21010; Inspection Report No. (A): FSPS-Wa 1962-A
The following data applies to the chimney characteristics in accordance with EN 13384-1 / 2:
Combustion Values
Nominal Thermal Output
Waste Gas Mass Flow Rate
Waste Gas Outlet Temp.
Min. Supply Pressure at Nominal Thermal Output
CO content at 13% O2
Efficiency
Particulate
Depending on the insulation of the building, the nominal thermal output of 4 kW indicated
on 10 - 50 m² (subject to change)
Dimensions: Height
Stove 135 cm
Fire box 34 cm
Weight:
Fire Box Opening:
Flue pipe diameter:
Pipe diameter of Hase ventilation system*
* For separate air supply in low-energy houses and insufficient combustion air supply in the
room where the stove is installed
38
All manuals and user guides at all-guides.com
Wood Briquettes
4 4 kW
4 4 g/s
280 280 ˚C
12 12 Pa
1059 1113 mg/m³
80 79 %
23 50 mg/m³
Width Depth
48 cm 41,5 cm
22 cm 27 cm
144
88 cm²
15 cm
10 cm
Front view
48
Top view
kg
Side view
6,5 Ø 24
Connection area for
the inst. of Hase air
system below
Dimensions in cm
