I/O Panel
1
**
16
17
No. Description
1 USB 3.2 Gen1 Ports (USB3_1234)*
2 2.5G LAN RJ-45 Port (Killer® E3100G)** 11
3 LAN RJ-45 Port (Intel® I219V)***
4 Central / Bass (Orange)
5 Rear Speaker (Black)
6 Line In (Light Blue)
7 Front Speaker (Lime)****
8 BIOS Flashback Button
9 Antenna Ports
4
5
3
2
14 13
15
No. Description
10
12
13
14
15
16
17
6
7
12 10
11
USB 3.2 Gen2 Type-A Port (USB31_TA_1)
USB 3.2 Gen2 Type-C Port (USB31_TC_1)
Microphone (Pink)
Optical SPDIF Out Port
USB 2.0 Ports (USB_12)
USB 3.2 Gen1 Ports (USB3_56)
DisplayPort 1.4
HDMI Port
Z690 PG Velocita
9 8
3
