Modster Mini Cito Betriebsanleitung Seite 20

User Manual
Fittings view
287370
4.9*13.6 Ball Head screw
assembly
287374
ST2.6*6PWB6 screw assem-
bly
287375
ST2.6*6PB screw
assembly
287401
Battery assembly
26258
M3 flange nut
20
287371
4.9*10.6 Ball Head screw
assembly
287379
M3*5 Inner hexagonal
screw assembly
287373
2.5*6PWM6 screw
assembly
287369
ST2.6*8KB screw
assembly
226025
3*20pm Cross round head
machine screw
287371
4*9.5 Ball Head screw
assembly
262470
Magic paste group
287380
M3 Loose nut assembly
287367
ST2.6*8PB screw
assembly
291515
2,5*8PWM6 Cross round
head machine screw
MODSTER Mini Cito
287368
ST2*8KB screw
assembly
287393
Ball bearings 7*11*3 groups
287381
Motor teeth 27T group
287366
ST2.6*10PB screw
assembly
www.modster.at
