Page EN-14 Assembly

Installing the mounting rails

(7)
1. Screw two mounting rails (7) with four
plate screws each,(8) four washers each
and (9) four nuts (10) in such a way that
the exhaust hood will later hang at the cor-
rect height.
(6)
2. Affix the mounting rails (7) with two plate
screws each (8), two washers (9) and two
nuts (10) on the ceiling panel (6).
4×
(8)
3. Hold the ceiling panel (6) with mounting
(9)
(10)
(8)
(9)
(10)
(7)
4. Affix the exhaust air hose (4) to the ceiling
rails (7) to the ceiling and affix it there with
the heavy-duty bolt anchors and fixing
screws.
outlet.
(6)
(7)
(4)
