ASSEMBLY/
Make sure to tighten all screws only
hand-tight. Use the tools provided.
FRONT WING
Items needed: 3x M6x20 mm Screw
Make sure your Fuselage is clean and no
sand particles contaminate the flange area
and the threads. Put some Tef gel onto your
screws to prevent corrosion. Screw the
BACK WING
Items needed: 2x M6x20mm Screw
Make sure the back wing, the screw and the
threads in the Fuselage are not contaminated
with sand or other abrasive particles. Apply
Tef Gel to the Screw and turn it clockwise
until the screw clamps the rear wing into its
final position.
en
Screws in clockwise and fasten them tightly
with the enclosed T30 screwdriver. Don´t use
tools with a bigger leaver arm as it may lead
to damaged threads and screws.
