3. Layout & Connections

3.1 Layout

Front Side:
12-24V Connector
12-24V T-Block
for optional
external
Power Supply
Power LED 2x USB 3.2 Gen 1
Upstream B-Port

3.2 Connections

+12V - 24V T-Block:
GND (Ground)
+12V - 24V
+12-24V Connector:
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
for optional
external
select the Upstream
Power Supply
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
ATTENTION!!!
Only for use with optionally available power supply unit!
Toggle Switch to
USB B-Port
16x USB 3.2 Gen 1
Downstream A-Port
12
EX-1526HMVS
USB 3.2 Gen 1 port 16
does not support USB 2.0
end devices!
