In-Line Wire Connector Instructions

You do not need to use the In-Line Wire Connectors. The Transmission Box can be wired directly
to the reverse light circuit by stripping the reverse light wires then twisting Transmission Box
wires to the exposed reverse light wires. Once connected, wrap with electrical tape. DO NOT
attempt this if you are not knowledgeable with electrical installation practices.
Insert the existing
wire to be tapped.
Insert the wire to
be attached.
- 17 -
Getting started
Crimp tap then
close lock
