english
Connection of power supply (green terminals 9- / 7+):
Type of power supply
Direct supply of the transmitter
supply unit
Power supply via pac-Bus
Input connections (blue terminals 10,11,12 and 13,14,15):
9163/*3-1*-**
-
Channel 2
+
-
Channel 1
+
Output connections (black terminals PIN 1,2,3 and 4,5,6)
9163/**-11-10
Channel 2
Channel 1

10.2 Settings

The device does not require a setting.
How to connect
Green terminals 9- and 7+
See chapter 9.3.1
9163/11-81-10
15 -
14 +
-
11 -
11 -
0..5 V
10 +
10 +
+
9163/*3-10-10
Operating Instructions
9163/11-81-10
-
11 -
0..10 V
12 +
+
Isolating Repeater Input Type 9163
19
