Preface
Dear Customer,
Thank you for purchasing this photo-electric smoke detector. You
made the right decision in choosing this state-of-the-art technology,
which complies with the current standards of domestic and European
regulations. The CE has been proven and all related certifications are
available from the manufacturer upon request. To maintain this status
and to guarantee safe operation, it is your obligation to observe these
operating instructions.
Notes
The smoke detector is used together with a burglar alarm system or
fire hazard warning system. It is used in locations with low dust
pollution (residential buildings, offices) or where thick smoke can be
expected in the event of a fire (such as smouldering furniture).
The smoke detector reacts to smoke that reaches its smoke chamber.
Caution:
Smoke detectors cannot be used to prevent fire. They are used
merely to react to specific fire characteristics. During installation, make
sure that the detector is placed in accordance with local fire
precaution regulations and recommendations.
This detector is designed for indoor use only.
To ensure perfect functioning of your smoke detector, please note the
following:
•
Do not disassemble the detector.
•
Avoid anything that may prevent the flow of air to the
detector.
Following installation, check that all detectors in your fire alarm system
are working and repeat this check at least once a year.
Positioning
For your own and your customers' safety, place the smoke detector
centrally above the area to be supervised. Make sure that the detector
is at least 30 cm away from any walls.
Use smoke detectors only in rooms with low dust pollution or where no
fires with highly flammable materials are expected.
Installation
1. Separate the detector from the base plate by pressing detector
and base plate together and unscrewing in an anticlockwise
direction.
2. Installing the base plate
2.1. Using the screws and wall-plugs supplied, screw the base
plate to the wall or ceiling.
2.2. The detector needs four connections cables for installation.
Fig. 1 shows the wiring diagram, Fig. 2 the base plate.
The connection mark numbers are also shown inside the
base plate.
