Cleaning And Maintenance - CONGA 3890 Titanium Bedienungsanleitung

ENGLISH
When a cleaning cycle has been completed or the robot's battery is low, thanks to its Total
Surface 2.0 technology, the robot will also return to the charging base to avoid running out of
battery. Once the robot has recharged, it will resume cleaning from the point it has stopped.
Note:
Remove the Wet & dry tank from the robot before charging it.
Make sure there are no obstacles in the room being cleaned to ensure the robot can get to the
charging base without problems.
Spiral mode
The robot is placed on a specific point, it starts cleaning in an outward spiral motion, and
then returns to the starting point in an inward spiral motion again. If the robot bumps into an
object, it will finish the cleaning cycle moving in the opposite direction in a spiral motion.
Manual mode
The robot can be manually controlled with the direction arrows on the display.
The robot will move in the selected direction as the arrow is being pressed.
It will also clean according to the suction power level and water intensity level selected on
the App home display.
Twice mode
When this mode is activated, the robot will first clean in Edge mode, then will carry out an
organized cleaning cycle in zig zag motion, then Edge mode again and another organized
cleaning cycle in zig zag motion. Once it has finished, it will return to the charging base, and if
it runs out of battery before finishing, it will recharge and then resume cleaning until finished.
This mode can only be activated during Edge, Scrubbing, Spiral and Smart Area modes.
Scrubbing mode
This robot also features Scrubbing function. When this mode is activated, the robot moves in
a swaying motion, simulating real scrubbing moves. It starts off by Edge mode, then carries
out an organized scrubbing cycle in zig zag motion, and finally returns to the charging base
taking the straightest way and memorizing the route. If it runs out of battery before finishing,
it will recharge and the resume cleaning until finished.
Spot cleaning mode
This mode can only be activated with a previously saved map. The user must select a specific
spot in the map, and the robot will clean a 2 x 2 m area around the selected spot. Once it has
finished cleaning it, it will smartly return to the charging base, taking the straightest way and
memorizing the route. Only one specific spot can be selected at a time.
42
Restricted Area
This mode can only be activated with a previously saved map. This mode allows setting areas
manually where the robot will not be allowed to clean. It starts cleaning outside the selected
area in Edge mode and then carries out an organized cleaning cycle in zig zag motion. The
user can set as many Restricted Areas as desired and choose the size of each of them.
Smart Area
This mode can only be activated with a previously saved map. This mode allows setting
specific areas that you want the robot to clean, without having to clean the whole surface. It
first carries out a cleaning cycle in zig zag motion inside the delimited area. The user can set
as many Smart Areas as desired and choose the size of each of them.
Final cleaning
Before returning to the charging base, the robot moves forward and backward several times
in order to eliminate any rests of dust from the brush.

6. CLEANING AND MAINTENANCE

Main brush
Turn the robot around and press the main brush's release button to take the cover out.
Take the main brush out and clean the compartment.
Clean the main brush with the provided tools and use water and soap if necessary.
Place the main brush in its position and fasten the cover's clip.
Recommendation: Replace the main brush every 6-12 months to ensure efficient operating
(depending on the frequency and type of use).
Fig. 17.
1. Main brush cover
2. Tab
3. Main brush
4. Compartment
Silicone brush
To clean the silicone brush, follow the instructions on the previous section to remove it from
the robot and wash it with water and soap. Dry it thoroughly before assembling it back in
order to ensure efficient operation.
Jalisco brush
To clean the Jalisco brush, follow the previous section's steps to take it out and clean it with
water.
ENGLISH
43
