4. Technical data

Motor power supply: ............................... 18 V DC
Stroke speed: ............................... 0 – 2,700 min
Stroke height: ........................................ 20.0 mm
Saw blade width ................................. 0.8-1.6 mm
Cutting depth, wood: ................................ 70 mm
Cutting depth, plastic: .............................. 10 mm
Cutting depth, iron/aluminium: ................... 8 mm
Miter cut: ....................... up to 45° (left and right)
Weight: .......................................................1.6 kg
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 62841.
L sound pressure level ..................... 79.5 dB(A)
pA
K uncertainty ............................................. 3 dB
pA
L sound power level ....................... 90.5 dB(A)
WA
K uncertainty ............................................. 3 dB
WA
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 62841.
Sawing particleboard
Vibration emission value a
K uncertainty = 1.5 m/s
2
Sawing sheet metal
Vibration emission value a
K uncertainty = 1.5 m/s
2
The stated vibration emission levels and stated
noise emission values were measured in ac-
cordance with a set of standardized criteria and
can be used to compare one power tool with
another.
The stated vibration emission levels and stated
noise emission values can also be used to make
an initial assessment of exposure.
Warning:
The vibration and noise emission levels may vary
from the level specifi ed during actual use, depen-
ding on the way in which the power tool is used,
especially the type of workpiece it is used for.
Anl_TC_JS_18_Li_SPK7.indb 21 Anl_TC_JS_18_Li_SPK7.indb 21
GB
Keep the noise emissions and vibrations to a
minimum.
•
-1
•
•
•
•
•
•
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
2. Damage to hearing if no suitable ear protec-
3. Health damage caused by hand-arm vib-

5. Before starting the equipment

Warning!
= 7.843 m/s Always remove the battery pack before making
2
h
adjustments to the equipment.
5.1 Safety guard (Fig. 2/Item 12)
•
= 8.932 m/s
2
h
•
•
5.2 Changing the saw blade (Fig. 3/Item 10)
Warning!
Remove the battery pack before you fi t or re-
place a saw blade.
•
•
- 21 -
Only use appliances which are in perfect wor-
king order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever ne-
cessary.
Switch the appliance off when it is not in use.
Wear protective gloves.
mask is used.
tion is used.
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
The safety guard (12) protects the user from
accidentally touching the saw blade (10) but
still gives you an unobstructed view of the
cutting area.
The safety guard (12) must always be fitted
and in position before starting any sawing
work.
The safety guard (12) can be pulled up as
shown in Fig. 2.
You can fit or replace saw blades without
using any other tools.
Set the selector switch for pendulum action
(7) to position A (see Fig. 11).
