Internal Tank Water Full Alarm Function
• The inner water tank in the air-conditioner has one water level safety
switch that controls the water level. When the water level reaches an
anticipated height, the water full indicator lamp lights up. Follow above
steps to drain the water.
INSTALLATION
• The air-conditioner should be installed on a flat and stable surface. Do
not block the air outlet and allow at least 30cm around the unit.
• Socket wiring should be in accordance with the local electric safety
requirements.

Exhaust Hose Installation

• Twist both ends of the hot-air exhaust hose(9) into the hose connector
window end(8) and the hose connector air conditioner end(10).
• Insert the hose connector air conditioned end(10) into the openings at
the back of the air conditioner.
2 4
77.777000.01.001_77.779000.01.001_IM.indd 24 77.777000.01.001_77.779000.01.001_IM.indd 24
30cm 30cm
12 inch 12 inch
